4-Column Classic Radiators Products
Showing 1 to 20 of 160 products
Frequently Asked Questions
Why is the 139mm depth important for installation planning?
The 139mm depth of the Budget Direct Classic 4 Column Radiators is a critical dimension that affects your pipework roughing in. Unlike standard panels, these radiators project significantly into the room. You must measure the distance from the wall to the pipe centers accurately, which is typically around 110mm depending on the bracket setting. Failing to account for this depth will result in pipes that do not align with the valves, requiring difficult adjustments to your floorboards or existing copper tails.
What are the safest mounting options for heavy 4 column radiators?
Due to the significant weight of these steel multi column units, especially when filled with water, standard wall fixing plugs are often insufficient for drywall. The most secure technical solution is to use Floor Mount Kits or Cast Feet to transfer the vertical load directly to the floor structure. These mounting options relieve the shear stress on the wall brackets, which should then be used primarily to stabilize the radiator upright rather than bearing the full weight.
Do I need to upgrade my central heating pump for these radiators?
These radiators have a much larger water capacity than standard panel radiators. While a standard domestic pump is usually sufficient, adding multiple large cheap budget direct own brand classic column radiators to a system increases the total water volume. You should verify that your expansion vessel is sized correctly to handle the increased expansion volume when the water heats up, preventing pressure relief valves from discharging.
How does the White RAL 9016 finish improve heating efficiency?
The White RAL 9016 Traffic White powder coating is not just an aesthetic choice but a functional one. White surfaces typically have high emissivity, meaning they radiate heat energy effectively into the room. Using this standard finish ensures that the high surface area of your Budget Direct Classic 4 Column Radiators operates at peak thermal efficiency, unlike chrome finishes which can trap heat inside the metal body.
Can I install these high output radiators on a stud partition wall?
Installing heavy 4 column radiators on a hollow stud wall requires specific structural preparation. You cannot rely on plasterboard fixings. You must locate the timber studs and use a Stud Wall Bracket Kit to bridge the gap between them, or open the wall to install timber noggins. If this is not possible, you must use floor mounting options to support the weight, as a fully filled 4 column radiator can easily tear out of unsupported plasterboard.
Why should I choose a 4 column radiator over a 2 or 3 column model?
The technical reason to select a 4 column model is to maximize BTU output in a limited horizontal space. A 4 column radiator has a depth of 139mm, providing nearly double the surface area of a 2 column model. This solves the problem of heating large rooms with high ceilings or poor insulation where you only have a narrow section of wall available for the radiator, allowing you to deliver high heat without using up all your wall space.
How do I prevent cold spots in these large volume radiators?
Large volume radiators like the cheap budget direct own brand classic column radiators can suffer from air locks or sludge accumulation. To solve cold spots at the top, you must bleed the radiator repeatedly during the first few weeks of operation. To solve cold spots at the bottom, you must ensure the system is flushed and treated with a high quality inhibitor to prevent sludge from blocking the flow channels in the deep 4 column sections.
Are these radiators suitable for low temperature heat pump systems?
Yes the Budget Direct Classic 4 Column Radiators are technically ideal for heat pump systems. Heat pumps operate at lower water temperatures around 45 degrees Celsius, which requires a larger radiator surface area to heat a room effectively. The deep 4 column design provides the massive surface area needed to emit sufficient heat at these lower temperatures, ensuring your home remains warm without the need for high boiler temperatures.
What valve orientation do I need for floor pipes with 4 column radiators?
Because the connections are on the sides at the bottom of the radiator, and the unit is 139mm deep, the pipes will sit quite far out from the wall. If your pipes come up from the floor, you should use Angled Valves. If your pipes come out of the wall, you would typically use Corner Valves or Angled Valves depending on the pipe height. Straight valves are rarely used unless the pipes run along the skirting board. Correct valve selection is crucial for a tidy installation of these mounting options.
How do I clean the internal columns of a 139mm deep radiator?
The deep structure of 4 column radiators creates complex air channels that can trap dust, which technically acts as an insulator and reduces heat transfer. To solve this, you need a long flexible radiator brush that can pass through the gaps between the columns. keeping these airways clear is essential for maintaining the convective airflow that allows cheap budget direct own brand classic column radiators to heat the room air efficiently.
